ARC TCB100 Flanged Cavity Barrier 115 x 150 x 1200mm (Bag of 15) by ARC Building Solutions

Code TCB100
£0.00
£63.23
Code TCB100
Available to order (7-10 working days) Sorry! We're out of stock
£0.00
£75.88
£0.00
£63.23
PDF View datasheet
Earn 0 reward points with this product.

Bulk buy discounts

Quantity PurchasedPrice
8 +£72.08£60.07
  • Description

    The ARC TCB100 Flanged Cavity Barrier is a high-performance fire barrier designed specifically for timber frame constructions. This product provides up to 60 minutes of fire integrity and 15 minutes of insulation, ensuring robust protection against the spread of fire and smoke within the cavity. Measuring 115 x 150 x 1200mm, it is suitable for cavity widths up to 100mm. Each bag contains 15 pieces, making it a practical and cost-effective solution for larger projects. The barrier is made from non-combustible rockfibre mineral wool with a thermal conductivity of 0.037W/mK, and is encapsulated in a durable polythene sleeve for added weather protection and ease of handling.

    Installation Guide:

    Option 1: Fixing to Timber Frame Before Brickwork

    1. Prepare the Barrier:
      • Measure and cut the barrier to the required length if necessary.
      • Use the polythene flanges to fix the ARC TCB100 to the timber frame inner leaf.
    2. Fix the Barrier:
      • Secure the barrier using clout nails or staples at approximately 150mm centers.
      • For vertical installations, use both flanges. For horizontal installations, use only the top flange.
    3. Ensure Tight Fit:
      • Butt joint lengths tightly at the end of a run or at corners to ensure no gaps remain.
    4. Complete Brickwork:
      • Lay brickwork to create the cavity, compressing the ARC TCB100 to its required fit.

    Option 2: Building in as Brickwork Progresses

    1. Prepare the Brickwork:
      • Build the brickwork up to the level where the barrier will be installed, ensuring the cavity width is correct.
      • Allow the brickwork to set.
    2. Install the Barrier:
      • Push fit the barrier into place under the correct compression.
      • Butt joint lengths tightly at the end of a run or at corners to ensure no gaps remain.

    General Tips & Advice:

    • The polythene encapsulation and flanges help hold the barrier in place and offer weather protection, but do not contribute to the barrier's performance. Leave the polythene intact.
    • Ensure the cavity width matches the design width for the installed barrier.
    • Avoid squashing the barrier before installation, as this can cause gaps and reduce performance.
