Rockwool SP/L Large Fixing Brackets for SP Fire Stop System to suit cavities 150 to 400mm (Box of 50) by Rockwool

The ROCKWOOL SP/L Large Fixing Brackets are integral components of the SP Fire Stop System, designed to secure fire-stopping slabs within cavities measuring up to 400 mm. These brackets ensure the stability and effectiveness of fire barriers in various construction applications, including cladding, curtain walling, and masonry wall cavities.

Key Features:

• Versatile Application: Suitable for cavity widths up to 400 mm, accommodating a range of building designs.

• Ease of Installation: Supplied flat-packed in boxes of 50, the brackets can be easily re-profiled by hand on-site to fit specific cavity dimensions.

• Robust Support: When properly installed, they provide essential support to SP FireStop Slabs, maintaining fire compartmentation and enhancing building safety.



Specifications:

• Product Code: SP/L

• Compatible Cavity Widths: Up to 400 mm

• Packaging: 50 brackets per box, flat-packed for convenient handling and storage



Installation Guidelines:

1. Preparation: Re-profile the SP/L brackets by hand to achieve the desired shape, ensuring they will penetrate at least 75% into the SP FireStop Slab.

2. Placement: Position the brackets at intervals of 500 mm (±10 mm) along the length of the fire-stopping slab, with the first bracket placed 250 mm (±10 mm) from the slab's end.

3. Fixing: Secure the brackets to the building structure using appropriate metal fixings suitable for the substrate material.

4. FireStop Slab Installation: Impale the SP FireStop Slabs onto the installed brackets, ensuring a tight fit within the cavity and tight butting between adjacent slabs to maintain continuous fire resistance.
