Ancon 25/14 Channel - 2.7m Length by Ancon - A Leviat Brand

The Ancon 25/14 Channel is a high-performance stainless steel brick tie channel designed to securely tie masonry walls to structural frames, including steel, concrete, or timber substrates. Supplied in 2.7-meter lengths, this channel is ideal for applications requiring ties through insulation layers up to 270mm thick.

Key Features & Benefits

• Versatile Application: Suitable for tying brickwork to various structural frames through insulation.
• Pre-Punched Holes: Features alternating 5.5mm and 9.5mm holes at 225mm centers for flexible fixing positions, even when cut on-site.
• Compatible Wall Ties: Works seamlessly with Ancon SD25 stainless steel or Teplo-BF-CT 25 basalt fibre wall ties, which can be positioned at any point along the channel's length.
• Durable Construction: Manufactured from high-quality stainless steel for enhanced corrosion resistance and longevity.

Technical Specifications

• Length: 2.7 meters
• Channel Dimensions: 25mm width x 14mm depth
• Material: Stainless Steel
• Hole Sizes: Alternating 5.5mm and 9.5mm pre-punched holes
• Compatible Fixings:Ancon CFS+ and CFS concrete screws, HTSS self-drilling screws
• Compliance: Meets BS EN 845-1 standards for wall ties and restraint systems

Applications

Ideal for use in cavity wall constructions where tying the outer masonry leaf to the inner structural frame is required. The Ancon 25/14 Channel system is particularly effective in applications involving:

• Brickwork to steel or concrete frames
• Timber frame constructions
• Situations requiring ties through insulation layers
• Projects necessitating adjustable tie positions for optimal masonry support

For detailed installation guidelines and technical support, please refer to the Ancon Surface Fixed Channels Technical Literature.
