Timloc Everdry Cavity Tray for Brickwork - Catchment by Timloc Building Products

The Timloc Everdry Cavity Tray for Brickwork – Catchment is a preformed damp-proof course (DPC) designed to collect and discharge water where a pitched roof meets a cavity wall, preventing moisture ingress and damp at the abutment base through a compatible weep unit.

Designed for external walls up to 120mm thick with cavity widths between 50mm and 110mm, it forms part of the Timloc Everdry Adjustable Stepped Cavity Tray system. The catchment tray is fitted at the lowest point of the run and works with corner trays to maintain a continuous barrier for roofs pitched at 15° or more.

Key facts:

• Collects and discharges water from cavity trays
• Installs at the lowest abutment point
• For 50–110mm cavities and walls up to 120mm
• Compatible with Timloc weep units
• Meets BBA and NHBC standards

This Timloc Everdry Catchment Tray provides lasting protection at roof junctions, helping to prevent water penetration and maintain structural performance.

Installation info:

Install at the base of the cavity tray run, ensuring a clear discharge route through a weep hole.
